INDRIVE® has a complete line of Hollow Shaft Drives.  The Hollow Shaft design can be configured for any type of prime mover generally used in the oilfield. Models and Specifications can be reviewed below:



INDRIVE® Hollow Shaft Drives Feature:

* Modular Design - for easier installation and service.

* Detachable Stuffing Box Assembly

* Split and Hinged Belt Guard and Motor Mounts

    - for easy access and adjustments.

* Axial Load Ratings - to fit any application

* Field Proven Reliability

* Heavy Duty and Durable

INDRIVE® Hollow Shaft Drives

HD & HR Series



HD15X 13,700 15
HR15X 13,700 7.5 Yes

HD15S 13,700 30
HR15S 13,700 15 Yes

HD15M 13,700 75
HR15M 13,700 40 Yes

HD25S 28,000 30
HR25S 28,000 15 Yes

HD25M 28,000 75
HR25M 28,000 40 Yes

HD25L 28,000 >75
HR25L 28,000 >40 Yes

HD50M 52,500 75
HR50M 52,500 40 Yes

HD50L 52,500 >75
HR50L 52,500 >40 Yes

Note: The last letter in the model name indicates the torque capacity of the back- spin brake:
         X= 400 ft-lb; S = 640 ft-lb; M = 2000 ft-lb; and L = 8000 ft-lb.
* HD (Direct Drive- No Gear Reducer) And HR (Right Angle Drive - Gear Reducer). Both Series.  Are Hollow Shaft Utilizing A Polished Rod Through The Main Shaft.
** Gas Engine Drive Systems USUALLY incorporate a pillow block assembly
+ Actual Hp Rating Is Dependent On The Speed And Torque Of The Application
